A.7. CONTROL SETTING CODES
The control setting codes used in the SVAN 977A instrument are given in the table below.
Table A.1. Unit parameters
Group name
#1
code
#7
code
#S
code
Code description
Unit type
U
977 (read only)
Unit subversion (read only)
US
x unit subversion
Serial number
N
xxxx (read only)
Software version
W
x.xx.x x.xx.x - revision number (read only)
Meter mode
Z
BE
0 - Vibration Meter
1 - Sound Meter
Voltage Input
V
0 - Off
1 - On
Measurement function
M
AL
1 - Level Meter
2 - 1/1 Octave
3 - 1/3 Octave
6 - FFT
8 - RT60
19 - STIPA
Microphone Compensation
MC
PN
0 - Off
1 - Free Field
2 - Diffuse Field
3 - Outdoor Environment
4 - Outdoor Airport
Remote Control Mode
RZ
0 - Off
1 - On
Windscreen
WD
0 - Off
1 - On
Range
R
AM
1 - Low
2 - High
Table A.2. Calibration parameters
Group name
#1
code
#7
code
#S
code
Code description
Auto Calibration
AC
0 - Off
1 - On
Calibration factor
Q
n.nn n.nn - calibration factor in dB
