Svantek SV 977D User Manual

214
SV 977D User Manual - Appendixes
Word
number
Name
Comment
11
RecFilter
measurement filter for the recorded signal:
0 – HP
1 – Z
2 – A
3 – C
5 – B
7 – U
8 – AU
12
BitsPerSample
number of bits per sample
13
TriggerOnMarker
marker triggering (parameter relevant only to triggering mode):
0 – disabled
1 – enabled
14
RecordingGain
signal amplification value in 0.01 dB format
…
reserved
Table B.12. Parameters of external port settings (Multifunction I/O)
Word
number
Name
Comment
0
0nn2Eh
2Eh = block identifier
0nnh = block length in words
1
Mode
port mode:
0 – analogue output (Analog Out)
1 – digital input (Digital In),
2 – digital output (Digital Out)
2
Function
port function for digital input mode:
0 – external triggering input
port function for digital output mode:
0 – external triggering pulse output
1 – alarm pulse output
3
ActiveLevel
impulse active level (parameter relevant only to alarm pulse function
in digital output mode):
0 – low active level (Low)
1 – high active level (High)
4
Source
triggering source (parameter relevant only for alarm pulse function in
digital output mode):
0 – triggering by RMS/Leq level from the first profile
1 – triggering by the Peak level from the first profile
2 – triggering by max level from the first profile
3 – triggering by P-P/Spl level from the first profile mode
5
SourceType
triggering type (parameter relevant only for alarm pulse function in
digital output mode)):
0 – triggering condition checked every second (Current)
1 – triggering condition checked after the end of the
measurement cycle (Periodic)
6
AlarmLevel
triggering threshold value in 0.01 dB format (parameter relevant only
to alarm function in digital output mode)
