SV 977D User Manual - Appendixes
3
FirstFreqIndex
index of the first filter; the exact centre filter frequency in Hertz
according to its index is given by the following formula:
f = 1000 · G
i/b
– for odd value b
f = 1000 · G
(2i+1)/(2b)
– for even value b
where:
G = 2 – for filter base 2
G = 10
0.3
– for filter base 10
i – filter index
b – octave division
4
N
number of values
5
T0_Offset[1]
First offset value
...
...
...
5+N-1
T0_Offset[N]
Last offset value
…
reserved
Table B.24. Alarms events parameters
Word
number
Name
Comment
0
0060h
60h = block identifier
1
BlockLength
block length in words
2
EventCount
number of defined events (Events)
3..10
EventName[1]
name of the first event (16 ASCII symbols)
11
reserved
12
EventType[1]
type of the first event:
0 – block event
1 – point event
...
parameters of the following events
…
reserved
Table B.25. STIPA parameters
Word
number
Name
Comment
0
0063h
63h = block identifier
1
BlockLength
block length in words
2
Standard
standard:
0 – IEC 60268-16x2
1 – IEC 60268-16x3
3
Averaging
averaging type:
0 – Manual
1 – Auto
4
N
Project name length
5..
ProjectName[N]
Project name
5+N
M
Area name length
6+N..
AreaName[M]
Area name
6+N+M
PointId
Point Id
7+N+M
K
Source name length
