SV 977D User Manual - Appendixes
Frequency
Compensation filter
for 0 deg incidence
angle “Outdoor
Airport”
Typical compensated
response of SV 977D
with SA 277D for 0 deg
incidence angle
Compensated Case
Effect of SA 277D for
0 deg incidence
angle
Uncertainty
(IEC 62585:2012)
[Hz]
[dB]
[dB]
[dB]
[dB]
12 589
1.33
-1.10
-0.79
0.35
12 957
2.61
-1.41
-1.22
0.35
13 335
3.59
-1.93
-1.60
0.35
13 725
4.11
-2.22
-2.07
0.35
14 125
4.10
-2.50
-2.25
0.35
14 538
3.56
-2.73
-2.74
0.35
14 962
2.59
-3.16
-3.13
0.35
15 399
1.42
-3.96
-3.95
0.35
15 849
0.38
-5.23
-5.33
0.35
16 312
-0.35
-6.81
-6.71
0.35
16 788
-0.91
-8.54
-8.42
0.35
17 278
-1.84
-10.38
-10.12
0.35
17 783
-3.75
-12.80
-12.56
0.35
18 302
-7.21
-16.47
-16.22
0.35
18 836
-12.73
-20.62
-20.57
0.35
19 387
-19.71
-27.10
-26.71
0.35
19 953
-22.89
-30.55
-30.34
0.35
Table C.7.12. SV 977D with SA 277D combined Free Field corrections with the use of the electrostatic
actuator for 0 deg incidence angle (microphone corrections + compensated Case Effect)
[dB]
Frequency [Hz]
20
25
31.5
40
50
63
80
100
125
160
200
250
315
400
500
630
800
Correction
factors
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
-0.16
-0.08
-0.04
-0.08
-0.17
-0.04
Complex
uncertainty
--
--
--
--
--
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.35
[dB]
Frequency [Hz]
1000
1250
1600
2000
2500
3150
4000
5000
6300
8000
10000
12500
16000
20000
Correction
factors
0.18
0.28
-0.32
0.38
0.06
0.90
1.70
2.15
3.01
4.17
5.77
6.10
3.89
-18.52
Complex
uncertainty
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.49
0.49
0.49
0.49
0.61
0.61
0.61
