Svantek SV 977D User Manual

347
SV 977D User Manual - Appendixes
11800 Hz
12500 Hz
Table C.7.1. Typical directional response of SV 977D with SA 277D (0 deg and 90 deg incidence angle ref.
0 deg)
Frequency
[Hz]
Angle [
o
]
0-10
10-20
20-30
30-40
40-50
50-60
60-70
70-80
80-90
90-100
250
-0.02
-0.03
-0.04
-0.04
-0.03
-0.03
-0.02
-0.01
0.01
0.03
315
0.00
0.01
0.02
0.02
0.04
0.04
0.06
0.07
0.09
0.11
400
0.00
0.00
-0.01
-0.03
-0.04
-0.07
-0.09
-0.12
-0.14
-0.16
500
0.01
0.02
0.03
0.04
0.05
0.05
0.06
0.06
0.07
0.07
630
0.00
0.01
0.01
0.01
0.01
0.02
0.03
0.03
0.03
0.02
800
-0.01
-0.03
-0.06
-0.10
-0.13
-0.15
-0.15
-0.14
-0.13
-0.16
1 000
0.02
0.04
0.05
0.06
0.06
0.05
-0.04
-0.08
-0.09
-0.07
1 250
-0.01
-0.05
-0.10
-0.17
-0.21
-0.22
-0.22
-0.29
-0.33
-0.33
1 600
0.01
-0.05
-0.10
-0.15
-0.21
-0.28
-0.35
-0.34
-0.25
-0.20
2 000
-0.01
-0.07
-0.19
-0.35
-0.48
-0.51
-0.48
-0.50
-0.51
-0.35
2 240
-0.02
-0.09
-0.21
-0.35
-0.53
-0.73
-0.76
-0.71
-0.76
-0.74
2 500
-0.03
-0.11
-0.26
-0.59
-0.72
-0.71
-0.92
-0.97
-0.86
-0.94
2 800
-0.05
-0.25
-0.52
-0.69
-0.77
-0.92
-0.93
-0.96
-1.09
-0.93
3 150
-0.12
-0.35
-0.52
-0.80
-1.02
-1.03
-0.96
-0.96
-1.03
-0.97
3 550
-0.03
-0.20
-0.44
-0.73
-0.91
-0.94
-0.95
-0.86
-0.85
-0.83
4 000
-0.12
-0.38
-0.64
-0.93
-1.04
-1.03
-0.90
-0.81
-0.60
-0.44
4 500
-0.09
-0.41
-0.92
-1.35
-1.48
-1.52
-1.67
-1.65
-1.51
-1.29
5 000
-0.27
-0.73
-1.29
-1.76
-1.78
-2.07
-2.07
-2.05
-1.88
-1.44
5 600
-0.16
-0.69
-1.17
-1.63
-2.03
-2.49
-2.69
-2.81
-2.86
-2.75
6 300
-0.29
-0.90
-1.55
-1.84
-2.28
-2.70
-2.97
-3.05
-3.13
-2.98
7 100
-0.11
-0.75
-1.09
-1.47
-1.57
-1.89
-2.11
-2.15
-1.95
-1.53
8 000
-0.61
-1.47
-2.35
-2.51
-2.33
-2.30
-2.53
-2.30
-2.34
-2.22
