SWF Dual Function E Series


3) Inserting X:2mm, Y:-5mm, Function code: Jump between 10000th stitch and
10001st stitch
󱀣 Move to the 10000th stitch using the scroll bar or Down key.
You will see a screen like [Fig.5.12.1-14].
󱀤 Select 10001th line.
You will see a screen like [Fig.5.12.1-15].
󱀥 Select .
󱀦 Press and input 2 from the keypad.
󱀧 Press and input -5 from the keypad.
󱀨 Press in [Fig.5.12.1-15].
[Fig.5.12.1-14] [Fig.5.12.1-15]
