X Driver Board Dip Switch Setting



Functions OFF ON
Reserved
Reserved
Reserved
Reserved
Reserved
Motor Setting
SELFTEST MODE
M/C Select
–
–
–
–
–
X Motor
Not in Use
1×1
–
–
–
–
–
Y Motor
In Use
Chenille
Y Driver Board Dip Switch Setting



Functions OFF ON
Reserved
Reserved
Reserved
Reserved
Reserved
Motor Setting
SELFTEST MODE
M/C Select
–
–
–
–
–
X Motor
Not in Use
1×1
–
–
–
–
–
Y Motor
In Use
Chenille
Select Dip Switch No. 1 depending on machine type (in the current machine type, it should be set at “Off”.)
