SWF Dual Function E Series


 Angle
rotates the design according to the set angle.
The basic setting is 0°. You can set within the range of 0-359° in the unit of 1°.
 Mirror
mirrors the design on the X, the Y, or the X_Y.
The basic setting is “0 (Normal)”.
<0°> <90°>
<No> <X Mirror>
<No> <Y Mirror>
<No> <X_Y Mirror>
Input Setting
0 Basic setting
1 X mirror
2 Y mirror
3 X_Y mirror
