SWF Dual Function E Series


(1) NEEDLE SELECT
It determines the order of the needle bars to be changed when the machine meets a color change code during
embroidery. Select NEEDLE SELECT in [Fig.5.9.4-1] and you will see keys required for selecting needle bar as
shown in [Fig.5.9.4-3]. Refer to the example below.
Keys activated when you select NEEDLE SELECT
① INSERT
② DELETE
③ -15 STEP
④ +15 STEP
⑤ SIMULATION
⑥ KEYPAD
⑦ -1 STEP
⑧ +1 STEP
⑨ RESET
⑩ OFFSET
⑪ OK
Refer to the example below for their functions.
[Fig.5.9.4-3]
[NOTE]
Needle bar setting will not be initialized after turning the power off and on again. The setting will not change if
you call another design. Therefore, if you want to change the setting or if you want to work on another design,
you must do the setting again.
