SWF Dual Function E Series

󱀩 Press .
[Ex.5.9.4-5] SELECTING ALL NEEDLE BAR PRESSER FOOT HEIGHT
Setting the presser foot height of all needle bars at 2.5mm.
󱀣 Perform [Ex.5.9.4.-1]
󱀤 The needle bar's presser foot height is set at 1.0mm as default.
󱀥 Press the Needle Height button.
󱀦 When the Needle Height button is pressed, EACH, ALL buttons are activated accordingly.
EACH button is selected as default, and then press ALL.
󱀧 Use the number keypad and press 5 among numbers 1 to 9.
As illustrated in <Fig. 5.9.4-17>, the presser foot height of all needles have been changed to 2.5mm.
[Fig.5.9.4-17]

