124 097-55501-01 Issue 6 – June 2003
1
TimeHub 5500 System Guide
3
(cont’d)
d. Finally, enable any specific port of interest by checking the associated check box for
the desired port. The control for this is in the center of the form, covering the entire
width. What can be viewed in the above form shows that ports 7 thru 26 are all turned
on. The scroll bar allows the other ports to be seen.
Requirements:
a. DS1 output waveforms must be as shown in Figure 4-11.
b. CC output waveforms must be as shown in Figure 4-12.
For DS1 output waveforms, only the positive pulse is shown. The negative pulse is an
upside down, mirror image of the positive pulse.
End of Procedure
N
OTE
: Do not tighten the mounting screws on the output driver
cards until instructed to do so in this chapter.
Procedure 4-6. Output Driver Card Installation (Cont’d)
Step Action
To Next Page
