V/D
S
ERIES
R
EGULAR TESTS AND MAINTENANCE
Revision: 2.1 5-13
The current gain and offset values are displayed with eight signed
significant digits.
SET GAIN OFFSET
Gain : 00.182750
Offset
: -149.48211
SAVE EXIT
Fig. 6: Calibration: Manual entry of the gain and offset values
• Enter the required gain and offset values:
Use the or button to navigate to the part that you would
like to change (digit, sign, change between gain and offset
value).
Change the value at the selected location with the or
buttons.
• Save the changed gain and offset values with the SAVE button. The
DONE confirmation message appears in the control unit display.
• Press the EXIT button to quit manual entry mode.
Changes can be discarded without saving them!
You can exit the mode for manual entry directly without
previously saving the values using the EXIT button. In this
case, any changes that you have made will be discarded.
2. Calculation of the gain and offset values using a reference
measurement from external test equipment
• Navigate to the Calc. GainOffset menu item and press the SET
button to calculate the gain and offset values.
