FlexSet Overview 7 FlexSet 120S/280S User Guide
FlexSet 280S with PEX Module - Bottom, Side and Rear View
FlexSet 280S with PEX Module - Bottom, Side and Rear View
LINE
DC
1st Handset
RJ-45 jack for optional
FlexSet 40B
Right
side
view
Rear view
Power Supply
(24 to 48 VDC)
RJ-11 jack
telephone line to
Coral system
Connection for
second handset
or monitor audio
Connection to
handset or
handsfree headset
2nd Handset
PEX
PEX
Bottom view
FlexSet 280S
