TRM-58: Hight voltage cable
Power entry socket – Circuit braker
Power entry
socket
Signal Color Circuit braker
Faston Neutral Blue Faston
Faston Line Brown Faston
CV-281: LCD inverter power supply cable
CPU board – LCD inverter
CPU board
CN5
Signal Color LCD inverter
CN1
1 +12 Vdc power supply Black 11
2 Reference Black 2
3 +3.3 Vdc power supply Black 4
4 Reference Black 3
5 +12 Vdc power supply Black 12
EAM2068: AT Driver board connecting cable
AT Power supply board – AT driver board
AT Power supply
board
XU2
Signal Color AT driver board
XU2
1 +12 Vdc power supply Blue 1
2 Gnd +12 Vdc Blue 2
3 + Sensing +5 Vdc Blue 3
4 - Sensing +5 Vdc Blue 4
5 +5 Vdc power supply Blue 5
6 Gnd +5 Vdc Blue 6
EAM2069: AT Driver board connecting cable
AT Power supply board – AT driver board
AT Power supply
board
XU1
Signal Color AT driver board
XU1
1 +24 Vdc power supply Blue 1
2 Gnd +24 Vdc Blue 2
3 +5 Vdc power supply Blue 3
4 Gnd +5 Vdc Blue 4
