Is the 400VdC v oltage
correctly supplied by the
AT driv er board?
Replace the AT driver
board
Is the voltage at the input
to the AT driv er board
correct?
NO
YES
NO
YES
6
Replace the power
supply board
5
A
B
Is the voltage at the input
to the AT driver box?
Replace mutual
inductance
NO
4
Is the voltage at the
output of the circuit
breakers correct, when
they are pressed?
Replace the circuit
breakers
NO
3
YES
YES
Is the EAM2068 cable
correct (check pin to pin)?
Replace the EAM2068
cable
NO
YES
Continued on the following page.
