69
To Use
Select the setup or reference waveform that you want to delete from the Delete command on the
File menu. To delete all Setups at the same time, select All Setups, to delete All Reference
Waveforms at one time select All Refs.
Behavior
You can only delete setups and reference waveforms stored in oscilloscope memory from this
command.
Setups or waveforms stored in Windows directories can be deleted by clicking the
in the Save
or Recall dialog boxes
Page Setup Dialog Box
Overview
Use the Page Setup dialog box to define the page setup before sending the data to a printer.
To Use
The controls in this window are similar to the Page Setup dialog box in most Windows
applications. The Paper settings are dependent on the type of printer connected to the instrument.
A reduced preview image appears at the top of the window. To view a larger image, click Print
Preview at the bottom of the window.
Click Print when you have selected all of your desired settings.
Behavior
The Type of printing should be Screen-copy for all screen shots. Banner printing should only be
used to print long continuous waveforms on the integrated thermal printer. For instructions on
printing banners, see Printing Banners.
Print Preview Dialog Box
Overview
Use the Print Preview dialog box to preview an image before sending the data to a printer.
To Use
Use the controls at the top of the window to zoom in and out to view the details of the image. To
return to the Page Setup dialog box, click Page Setup at the top of the control window. Click Print
to open the Print dialog box.
Print Dialog Box
Overview
Use the Print dialog box to send data to a printer.
To Next Page
