Turns Ratio Measurement
12.2.3 Tables
This table describes the method used to measure a certain transformer configuration. ZN is
always handled the same way as Z. For simplicity the connection table is valid for a 0 or 1 clock
number. For other clock numbers the connections are rotated/inversed accordingly.
VR:TR
Factor applied from Ratio Raw to Ratio Voltage
TR:VR
Factor applied from Ratio Voltage to Ratio Turns
TR Method
Method used to calculate the Ratio Turns
True TR
simply apply the TR:VR factor.
Con HV
HV Terminals used to perform a certain measurement
Con LV
LV Terminals used to perform a certain measurement
