Standby Initializing Charging Measuring Discharging
Reset
Standby
When the device has reached the Measuring state, it will immediately start to record data sets.
The sequence can be stopped anytime by sending
Meas:Stop
One can observe the current measured values during the whole process using
Res:Meas:R?
Res:Meas:U?
Res:Meas:I?
Res:Meas:T?
Temp:Values?
Recorded values can be obtained using
HR:Data? HV,2,1
HR:Data? LV,2,1
HR:Data? HV,2,2
HR:Data? LV,2,2
HR:Data? HV,2,3
HR:Data? LV,2,3
…
If a measuring process aborts unexpectedly or the system state is Reset or Interlock, one
can get an error message using
Meas:Error
22.4.4 Demagnetization
First, start with REN. This will enable remote controlling and it will transfer the current local set of
settings to the remote set of settings. Then send all settings to the device and at the end call
RemoteToLocal to transfer the remote settings to the local settings.
REN
Meas:Set:App DEM
DUT:Set:Vectorgroup YN,YN,0,D,5
