If the transformer is equipped with tap changer and it has been configured in the device, the tap
changer measuring sequence should be defined. Different options are available in the Tap
Control folder, selecting the setup in the main menu.
Measurement will be done tap by tap (no sequence to be
followed), the tap to be measured can be manually selected
in the main screen.
Only the nominal, upper and bottom taps will be measured
Several or all taps will be measured following a sequence
7.3.6 Auto recording configuration
Measurement can be done in auto stop mode
(value is automatically recorded when stable)
or in manual mode (unit stays measuring until
the operator click the stop button), selection
between both operations modes is done in the
setup screen, Data folder.
To record a value while measuring on this
mode, click the record button in the function
key bar.
If Automatic mode is selected, two pre-programmed stabilization parameters are available, in
addition the user can introduce any value manually.
