Shortcut to DUT setup. Similar to pressing
on main screen
13.5.8 Measuring
Performing a measurement on a transformer is quite simple. Once all transformer and options
have been introduced; just click the start button. The instrument will perform all operations
automatically.
It is recommended to perform transformer demagnetization before measuring the magnetic
balance, as residual magnetism can influence the test results.
Click start button to initiate the
test
Automatic measurement running
If auto recording is active, instrument will record the value and stop the measurement when the
stabilization condition has been reached.
If manual recording is active, the instrument will
repeatedly measure a phase.
Pressing the record button stores the latest result
and moves to the next phase.
