22.4.3 Heat Run
REN
Meas:Set:App HR
Res:Set:YNMode PhPh
DUT:Set:Vectorgroup YN,YN,0,D,5
Res:Set:Current HV,2.2
Res:Set:Current LV,8.9
Res:Set:Current TV,13.2
HR:Set:Phase:Select 2
Res:Set:Winding:Select HV-LV
HR:Set:Interval 5
HR:Set:NumPoints 100
RemoteToLocal
After sending all the settings, a
Meas:Start
will start the Heat Run sequence. The start command will only start the timer when switching the
transformer heating supply off. When the 2293 is connected to transformer and everything is
ready for cooling curve acquisition, the command
Meas:Continue
will start the actual resistance measuring process. After the measurement has started, the
measuring sequence and mode can be obtained using
Res:Meas:Sequence?
The result of this query helps to find out which winding and phase the device is currently
measuring.
Meas:State
Has to be used to find out in which state within a sequence step the device currently is. For
cooling curve measurement the state flow will typically look like
