Tettex 2293 - Options and Accessories; Optional Features

10
Introduction
1
2293 Winding Analyzer Instrument
1
High voltage side (H) measuring adaptor, 0.5m
1
Low voltage side (X) measuring adaptor, 0.5m
4
High voltage side (H) measuring cables, 4 units, (U, V, W, N) with clamp, 10m
4
Low voltage side (X) measuring cables, 4 units, (u, v, w, n) with clamp, 10m
1
Mains cable
1
Operating Instructions
1
carrying bag for cables and accessories
1
Spare kit (Printer paper roll, Fuses)
Once receipt of the unit check that all items have been delivered. Also check that the correct
power cord for your location has been supplied. In the event of missing or damaged parts please
contact you local sales representative stating the serial number and type of the instrument and
the sales order number.
1.3.2 Options and accessories
For detailed information about accessories and options please refer to the chapter 21
“Accessories and spares”
1.4 Optional features
The 2293 is equipped with optional features. These optional features can be enabled using the
license manager. . For getting licenses for new features contact our sales department
(sales@haefely.com)
2293/SKTTR
3-phase transformer turns ratio measurement add on application
for 2293
2293/SKAP
Arbitrary phase shift add on application for the 2293,
(2293/SKTTR needed)
2293/SKTR
Heat rise add on application for the 2293
2293/SKMB
Magnetic balance add on application for the 2293
2293/SKSI
Short circuit impedance add on for the 2293
2293/SKTC
Tap changer add on for the 2293
Additional features will be added to the device regularly, for a complete list or for questions please
check in our web page (www.haefely-hipotronics.com).
To activate the additional features (software keys) please read chapter 16- Optional Features
activation, of this manual.
