Tettex 2293 - Programming Examples; Resistance Measurement

Remote Control
201
• Dem:Set:Cycles
Sets and returns the maximum number of cycles to be performed when demagnetizing.
- Set: Dem:Set:Cycles [NCycles]
[NCycles] = 3 … 50
- Query: Dem:Set:Cycles?
 [NCycles]
• Dem:Meas
Returns the current set of measurements used in the demagnetization process. The
current
demagnetization cycle [CycleAct], the remanence flux determined during analysis
[FluxRemanence],
the current magnetic flux [FluxAct], the induced voltage [UInduced], the current [I] and the
winding
resistance [R].
- Query: Dem:Meas?
 [CycleAct],[FluxRemanence],[FluxAct],[UInduced],[I],[R]
22.4 Programming examples
22.4.1 Resistance Measurement
First, start with REN. This will enable remote controlling and it will transfer the current local set of
settings to the remote set of settings. Then send all settings to the device and at the end call
RemoteToLocal to transfer the remote settings to the local settings.
REN
Meas:Set:App RES
Res:Set:Mode Auto
Res:Set:YNMode PhPh
DUT:Set:Vectorgroup YN,YN,0,D,5
DUT:Set:TempCoeff CopperANSI,CopperIEC,Aluminium
Res:Set:Temp:Man 18.9
Res:Set:Temp:Ref 75.0
Res:Set:Temp:Use 0,1,0,0,0,0,1
Res:Set:Temp:Enable 1
Res:Set:Current HV,2.2
