10 Heat Run - Temperature
Rise
10.1 Overview
The 2293 is equipped with an optional temperature rise function. This optional feature is enabled
using the license manager. This process only needs to be completed the first time temperature
rise is used.
See chapter “Heat Run Cooling Curve” for a description of the theory of this test. Temperature
rise performs the total loss injection and rated current injection phase of the heat run test before
switching to the cooling curve function to perform the final phase of the heat run test.
10.2 User Interface
To access to the license manager, select
setup function key in the bottom bar of any
application
