7.2.2 Function keys during resistance in automated mode
While in automated resistance measurement mode, following actions are available in the button
key. The buttons are case sensitive, i.e. they change according to the actual status.
Record a result while manual recording mode is used
Calculate the winding resistance based on the results of the combined
measured resistance when a delta type transformers is measured.
Move tap changer one step down
Move tap changer one step up
Change display to list mode
Change display to graphic mode
Open setup menu for the selected measuring application
7.2.3 Active Window
The automated resistance measurement screen is bellow described:
