• HR:Set:Phase:Select
Sets and returns the phase selection for the heat run test. Issuing the set command with
only a phase
argument selects the corresponding two phases of the currently selected windings. By
adding a
winding argument, the selection can be reduced to only one phase on only one winding.
- Set: HR:Set:Phase:Select [Phase],[Winding]
[Phase] = 1 ¦ 2 ¦ 3
[Winding] = HV ¦ LV ¦ TV
HR:Set:Phase:Select [Phase]
[Phase] = 1 ¦ 2 ¦ 3
- Query: HR:Set:Phase:Select?
HV,[Ph1],[Ph2],[Ph3];LV,[Ph1],[Ph2],[Ph3];TV,[Ph1],[Ph2],[Ph3]
[Ph] = 0 ¦ 1
• HR:Data
Returns a measurement set (Time [t] in seconds, Resistance [R], Voltage [U], Current [I],
Temperature
[T]) for a given winding, phase and index. The index is used to access various points
recorded. Each
successful query returns [IndexCurrent] which shows the amount of points recorded so
far. When
[IndexCurrent] has reached [NPoints] the heat run recording is finished and the device will
discharge
the DUT.
- Query: HR:Data? [Winding],[Phase],[Index]
[Winding] = HV ¦ LV ¦ TV
[Phase] = 1 ¦ 2 ¦ 3
[Index] = 1 … 1000
[IndexCurrent],[t],[R],[U],[I],[T1],[T2],[T3],[T4],[T5],[T6]
[IndexCurrent],- (No data for this index available)
- (No data for this winding and phase available)
• Dem:Set:Phase
Sets and returns the phase on which the demagnetizazion shall be performed.
- Set: Dem:Set:Phase [Winding],[Phase]
