UDL & Digi Options Premier Elite Series Installation Manual
104 INS176-15
• Click on Site Name and enter a Site Name & Site Summary
• Click Back and then IP Details, enter the IP address and Host
Port of the ComIP from the previous steps in these
instructions.
o Update IP should be enabled if you want to setup
Push Notifications. (Unless you are using your own
Dynamic DNS)
o Stay Connected stops the app disconnecting from
the control panel when swiping between screens.
• Click Back then Security Details, enter the UDL Password
from the Control Panel. This cannot be left blank and must
match the Control Panel UDL password. For details on
Protected UDL Password please see the app Instruction
Manual.
• Click Back and then User Areas, Enter the User Code that
you use with the Control Panel and the User Number (iOS)
User ID (Android). The User Number/ID will be for example 1,
do not type User 1.
The app is now set up for Local (LAN) connections.
Remote connection & Push Notifications
For remote connections it is highly recommended that you enable
Push Notifications. This will mean that Texecom will track the IP
address and update it as required. If the service provider does not
provide you with a fixed IP address (most don't) you will require a
third party DDNS provider to allow the app to operate remotely if
you do not "Enable" push notifications.
Port Forwarding must be setup on the router to allow
remote connections. Please see Page 46
Follow the instructions given above for Local Connections and then
do the following:
• Click on My Sites then enter Edit mode for the chosen site.
• Click on Notifications. You must press Yes and accept the
disclaimer before you can proceed.
• Choose & enter a User Name
• Choose & enter a Password
• Enter a valid Email Address (Notifications will not be setup
without a valid address)
• Leave the Account Number field blank.
• Click Register Account
You will receive an email with a Verification Code, follow the
instructions in the email. Enter the Verification Code you are given
into the Account Number box and press Register. Once you have
completed this step the Account Number will be automatically
populated with an Account Number allocated by the Server.
Record all of the details here for future use, and if you choose to
add an additional device to receive notifications from the same site.
Setting up additional devices to receive notifications from the same
site requires that ALL details are Identical all devices. This includes
the Site Name & Site Summary, and are case sensitive. To
register an additional device complete all details for the Site. On the
Registration page complete all details including the Account
Number you now have and press Register.
Push Notification Account Number
Texecom App Server Information
15 Minutes Poll Timer MUST be set
ARC Settings & Reporting Options
• Enter the Engineers Code
• Press y/ (UDL/Digi Options)then (Program
Digi) y/
• Using the Scroll key select Which ARC you wish to use
• Press n/ and scroll to change the ARC protocol to either
SIAII or Contact ID, both are supported.
• Press y/ twice then n/
• In the Pri. Tel No: screen enter the Push Notification Sever
Address exactly like this: 54.88.92.200/10001 To enter the dot
press the / key twice. To enter the / press the C/
key twice
o 54.88.92.200/10001
• Press y/ twice then n/
• In the Sec. Tel No: screen enter the Push Notification Sever
Address exactly like this: 52.28.12.230/10001 To enter the dot
press the / key twice. To enter the / press the C/
key twice
o 52.28.12.230/10001
• Press y/
• Press n/ and then enter the six digit XXXXXX Account
Number you were given in the app
• Press y/ then n/ (Dial Attempts) enter a minimum
of 6
• Press y/ twice
• Press n/ and edit the Areas you wish to receive
notifications for.
• Press y/ then n/ and toggle the reporting options
on or off, depending on what you want to receive notifications
of. Use the n/ button to toggle each option on or off.
• Press y/ then n/ and scroll across the screen and
use the n/ button to toggle option 7 Connect Via IP ON
(an I will be shown on the screen)
• If you chose SIAII as the Protocol in previous steps scroll once
more to Option 8 and toggle Send SIA Text to ON (a T will be
shown).
• V3 or later only y/ twice then n/ and select which
Com Port the IP details apply too.
• Press y/
DO NOT EXIT ENGINEERS MODE YOU MUST SETUP POLLING
FOR THE SYSTEM TO WORK CORRECTLY.
Control Panel Setup for Polling
To setup the Control Panel for Polling do the following:
• Press N/ twice
• Press then y/ twice (Global Options/System
Timers)
• Scroll to Poll IP Every
• Press n/ and then enter a value 15 minutes (015).
The polling time is controlled by the server and may be
changed.
Enable Digi, Dial All Numbers & Test Call
To test the settings, initialize a Push Notification and update the IP
address in the app a test call should be carried out. Please ensure
the Digi is Enabled & Dial All Numbers is enabled for systems with
multiple communication devices installed.
Digi Enabled & Dial All Numbers
If you have more than one communication device connected to the
control panel, Dial All Numbers MUST be enabled; continuing from
the previous steps:
• Press N/ then (Digi Options)
• Press y/ then n/ scroll through the options and
ensure Digi is Enabled (E shown on Screen) and Dial All
To Next Page
