Texecom Premier Elite Series Installation Manual

Specifications Premier Elite Series Installation Manual
148 INS176-15
Environmental
Operating Temperature
-10C (+14F) to
+55C (+131F)
Storage Temperature
-20C (-4F) to
+60C (+140F)
Maximum Humidity
95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D)
145mm x 115mm x 30mm
Packed Weight
260g Approx.
Zone Expanders
Electrical
Operating Voltage
10 - 14VDC
ACE Type
B
Current Consumption 4XP 8XP
Quiescent
Alarm (Nothing Connected)
65mA
65mA
Data Network
4-wire standard 7/0.2 alarm cable
up to 500m Star, Daisy Chain or
any combination of the two
Zones
8XP
60IXD
8 DP or EOL zones
60 iD zones (2 loops)
EOL Resistor Values
EOL Resistor
Contact Resistor
Fault Resistor
0 - 1k
1k1 to 4k
4k1 to 5k6
5k7 to 8k
8k1 to 20k (30k)
21k+ (30k+)
(Alternatives Available)
2k2 (3k3)
4k7 (3k3)
2k2
Zone Short
Zone Secure
Zone Fault
Zone Active
Zone Mask
Zone Tamper
Outputs
Outputs 1 & 2 (4XP)
Outputs 1 - 8 (8XP)
100mA switched to 0V
100mA switched to 0V
Speaker Output (4XP & 8XP)
Minimum load 8
Environmental
Operating Temperature
-10C (+14F) to
+55C (+131F)
Storage Temperature
-20C (-4F) to
+60C (+140F)
Maximum Humidity
95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D)
170mm x 140mm x 35mm
Packed Weight
200g Approx.
Output Expanders
Electrical
Operating Voltage
9 - 13.7VDC
ACE Type
B
Current Consumption
Quiescent
Alarm (Nothing Connected)
65mA
65mA
Network
4-wire standard 7/0.2 alarm cable up
to 250m Star, Daisy Chain or any
combination of the two
Bank 1 Outputs
Outputs 1 to 8
Bank 2 Outputs
Outputs 1 to 8
100mA switched to 0V
100mA switched to 0V
Environmental
Operating Temperature
-10C (+14F) to
+55C (+131F)
Storage Temperature
-20C (-4F) to
+60C (+140F)
Maximum Humidity
95% non-condensing
EMC Environment
Residential
Commercial
Light Industrial
Industrial
Physical
Dimensions (W x H x D)
170mm x 140mm x 35mm
Packed Weight
200g Approx.
Product Variants and Compliance
Products are compliant with EN50131-3:2009
Product Type
Description
Security Grade
Environmental
class
EN50131-3:2009
INCERT
T 031 / T 014:2013
CAFA1000
Premier Elite 12 Poly
2
II
Telefication
T 031- Telefication
CAA1010-3
Premier Elite 24 Poly
2
II
Telefication
T 031- Telefication
CAA1020-3
Premier Elite 24 Metal
3
II
Intertek Tick Mark
T 031- Telefication
CAB1020-2
Premier Elite 48
3
II
Intertek Tick Mark
T 014 – Telefication
CAC1020-2
Premier Elite 88
3
II
Intertek Tick Mark
T 014 – Telefication
CAD1020-2
Premier Elite 168
3
II
Intertek Tick Mark
T 014 – Telefication
CAE1020-2
Premier Elite 640
3
II
GEA1000
Premier Elite 48-W
2
II
T 014 – Telefication
GED1000
Premier Elite 24-W
2
II
T 014 – Telefication
GEHA1000
Premier Elite 12-W
2
II
T 014 – Telefication
GEWA1000
Premier Elite 64-W 868Mhz
2
II
GEWA2000
Premier Elite 64-W 433Mhz
2
II
GEWA3000
Premier Elite 64-W 866Mhz
2
II
GEXA1000
Premier Elite 64-W Live Front
868Mhz
2
II
GEXA3000
Premier Elite 64-W Live Front
866Mhz
2
II

Texecom Premier Elite Series Specifications

General

Event Log	1000 events
Expanders	Supports up to 8 expanders
Wired Zones	Up to 48 wired zones
Wireless Zones	Up to 64 wireless zones
Batteries	12V 7Ah
Tamper Protection	Yes
Outputs	Up to 8 outputs
Battery Backup	Yes
Compatibility	Compatible with Texecom accessories
Dimensions	Varies depending on model
Weight	Varies depending on model
