Texecom Premier Elite Series Installation Manual

Installation Premier Elite Series Installation Manual
18 INS176-15
Power Supply Ratings
If installing to EN50131 or PD6662, the system standby times in the event of a mains power failure vary depending on the grade and how AC fail is
signalled:
 When calculating the current consumption of the system you must include the current taken by the control panel and all the devices that it
powers. If the total current exceeds the “Rated Output” for the grade you are installing to then an additional power supply is required
Premier Elite 24 (Metal)
Current
Current Consumption
95mA
Maximum Current Available
0.75A charge
1.0A
0.3A charge
1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 7Ah
0.3A
0.48A
0.19A
0.13A
0.021A
1 x 17Ah
0.3A
1.32A
0.61A
0.47A
0.18A
0.75A
1.0A
0.61A
0.47A
0.18A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby
Period
12h
12h
30h *
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery
Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah
< 24Hrs
0.3 A
1 x 17Ah
< 24Hrs
0.75 A
< 72Hrs
0.3 A
Premier Elite 24 (Polymer)
Current
Current Consumption
95mA
Maximum Current Available
0.3A charge
1.1A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah
0.3A
0.48A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Minimum Standby Period
12h
12h
Maximum Recharge Time
72 Hrs
72 Hrs
PD6662
Grade 1
Grade 2
Standby Period
12 Hrs
12 Hrs
Maximum Recharge Time
72 Hrs
72 Hrs
Premier Elite 48/88/168
Current
Current Consumption
125mA
Maximum Current Available
0.75A charge
1.0A
0.3A charge
1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 7Ah
0.3A
0.458A
0.166A
0.108A
1 x 17Ah
0.3A
1.29A
0.583A
0.441A
0.158A
0.75A
1.0A
0.583A
0.441A
0.1588A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby
Period
12h
12h
30h *
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery
Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah
< 24Hrs
0.3 A
1 x 17Ah
< 24Hrs
0.75 A
< 72Hrs
0.3 A
Premier Elite 640
Current
Current Consumption
125mA
Maximum Current Available
0.75A charge
1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 17Ah
0.75A
1.0A
0.558A
0.416A
0.133A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby
Period
12h
12h
30h *
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge
Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Premier Elite 12-W, 24-W & 48/64-W
Current
Current Consumption
150mA
Maximum Current Available
0.3A charge
1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah
0.3A
0.433A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Minimum Standby Period
12h
12h
Maximum Recharge Time
72 Hrs
72 Hrs
PD6662
Grade 1
Grade 2
Standby Period
12 Hrs
12 Hrs
Maximum Recharge Time
72 Hrs
72 Hrs

Texecom Premier Elite Series Specifications

General

Event Log	1000 events
Expanders	Supports up to 8 expanders
Wired Zones	Up to 48 wired zones
Wireless Zones	Up to 64 wireless zones
Batteries	12V 7Ah
Tamper Protection	Yes
Outputs	Up to 8 outputs
Battery Backup	Yes
Compatibility	Compatible with Texecom accessories
Dimensions	Varies depending on model
Weight	Varies depending on model
