Texecom Premier Elite Series Installation Manual

System Overview Premier Elite Series Installation Manual
4 INS176-15
1. System Overview
System Architecture
8 Programmable***
100mA Outputs
Bell Tamper Input
Auxiliary Tamper Input
5 Programmable Outputs
(4 x 500mA & 1 Relay)
( only)Premier 88 168, & 640
Premier Elite
48/ 88/12/24/ 64/
/640*168
Premier LCD/LCDP Premier LCDL/LCDLP
Premier Elite LCDLP/SMK/FMK
4 Wire Data Network 1
16 Programmable
100mA Outputs
2 keypads ( 12-W)Elite
4 keypads ( /W)Elite 24
4 Keypads ( & 64/W)Elite 48
8 Keypads ( )Elite 88
16 Keypads ( )Elite 168
64 Keypads ( ) Elite 640
Premier OP16******
1 Output Module ( )Elite 12**
1 Output Module ( )Elite 24
2 Output Modules ( & 64)Elite 48
4 Output Modules ( )Elite 88
8 Output Modules ( )Elite 168
32 Output Modules( ) Elite 640
8 Zone Inputs
Alarm Receiving
Centre
Modem
PC and Modem for
Remote Upload/Download
PC-Com
PC and forPC-Com
Local Upload/Download
Plug on Digimodem
(Com300, Com2400)
GSM Module
ComIP, ComWiFi*****
WebwayOne, Emizon
or Chiron Iris
2 Zone
Inputs
1Programmable
100mA Output
2 Zone
Inputs
1Programmable
100mA Output
Speaker
Output
Additional
4 Wire Data Network
Speaker Output
8 Zone Inputs
Auxiliary Input
Premier 8XP****
8 Programmable
100mA Outputs
0 Expanders ( )Elite 12
2 Expanders ( )Elite 24
4 Expanders ( & 64)Elite 48
8 Expanders ( )Elite 88
16 Expanders ( )Elite 168
64 Expanders ( )Elite 640
Wire as Network 1
4 to 16 Zones ( 12-W)Elite
8/4 to 24 zones ( /W)Elite 24
8/4 to 48 Zones ( /W)Elite 48
4 to 76 Zones ( 64-W)Elite
8 to 88 Zones ( )Elite 88
8 to 168 Zones ( )Elite 168
0 to 640 Zones ( ) Elite 640
Power
Info.
Ready
ServiceOmi
Power
Info.
Ready
ServiceOmit
Bell/Strobe Outputs
Area
Yes
Part
Chime
Omit Rese t
Menu
2 abc
No
1 3 def
6 mno
9 wxyz
5 jkl
8 tuv
0
4 ghi
7 pqrs
Area
Yes
Part
Chime
Omit Rese t
Menu
2 abc
No
1 3 def
6 mno
9 wxyz
5 jkl
8 tuv
0
4 ghi
7 pqrs
Premier
Power
Network No
Address
Zones
Power
Network No
Addre ss
Zone s
* No Onboard Zones
** 8 Only on Elite 12
*** 3 Only on Elite 12
**** When mixing wired and wireless expanders check total zone capacity for the control panel.
*****ComWiFi should not be used as a primary form of signalling to an ARC
****** Cannot be used at the same address as Wireless expanders
Premier 8XPElite -W****
Power
Network No
Address
Zones
0 Expanders ( )Elite 12
2 Expanders ( )Elite 24
4 Expanders ( )Elite 48
8 Expanders ( )Elite 64 & 88
16 Expanders ( )Elite 168
64 Expanders ( )Elite 640
Premier XP Elite 32 -W****
Power
Network No
Address
Zones
0 Expanders ( )Elite 12
1 Expanders ( )Elite 24
1 Expanders ( )Elite 48
2 Expanders ( )Elite 64 & 88
4 Expanders ( )Elite 168
16 Expanders ( )Elite 640
Mobile APP Server
Push Notifications/Arm/Disram
iOS
or
Android
Device
Control Panel
Premier Elite 24
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 24 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 4 keypads and 2 zone expanders
• Up to 1 output module
• 2 independent areas each with 3 part arms
• 2 area arm suites
• 25 programmable User codes
• 500 Event Log (time & date stamped)
• 1 programmable panel outputs (1 x 100mA )
• 1.5 Amp power supply (plastic Case)
Premier Elite 48
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 48 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 4 keypads and 4 zone expanders
• Up to 2 output modules
• 4 independent areas each with 3 part arms
• 4 area arm suites
• 50 programmable User codes
• 500 Event Log (time & date stamped)
• 2 programmable panel outputs (2 x 1A )
• 2.5 Amp power supply
Premier Elite 12/24/48 & 64-W & Live front
• 4 Onboard Zones
• 8 wireless device Ricochet enabled receiver onboard (12-W)
• 16 wireless device Ricochet enabled receiver onboard (24-W)
• 32 wireless device Ricochet enabled receiver onboard (48/64-W)
• Expandable to 16/24/44/76 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• 2-4 keypads and 0/2/3 zone expanders
• 1-2 output modules
• 2 or 4 independent areas each with 3 part arms
• 2 or 4 area arm suites
• 8/25/50 programmable User codes
• 250/500 Event Log (time & date stamped)
• 1 or 2 programmable panel outputs (2 x 500mA )
• 1.5 Amp power supply
Premier Elite 88
• 8 fully programmable Double Pole or End Of Line zones
• Expandable to 88 zones via keypads and zone expanders
• 1 x 4-wire data network (standard 7/0.2 alarm cable)
• Up to 8 keypads and 8 zone expanders
• Up to 4 output modules
• 8 independent areas each with 3 part arms
• 8 area arm suites
• 100 programmable User codes
• 1000 Event Log (time & date stamped)
• 5 programmable panel outputs (4 x 1A & 3A relay)
• 2.5 Amp power supply

Texecom Premier Elite Series Specifications

General

Event Log	1000 events
Expanders	Supports up to 8 expanders
Wired Zones	Up to 48 wired zones
Wireless Zones	Up to 64 wireless zones
Batteries	12V 7Ah
Tamper Protection	Yes
Outputs	Up to 8 outputs
Battery Backup	Yes
Compatibility	Compatible with Texecom accessories
Dimensions	Varies depending on model
Weight	Varies depending on model
