These options control various system functions.
0 - Advisory Volume
Controls the volume of advisory tones (entry/exit etc.) from
loudspeakers connected to the control panel (Alarm tones are always
full volume). 1 = min, 8 = max.
1 - Chime Volume
Controls the volume level of Chime tones from ALL loudspeakers. 1 =
min, 8 = max.
2 - No. Of Re-Arms
Controls the number of times that a zone will re-arm. Once the re-arm limit
has been reached, the zone is ‘Locked Out’ and will not cause any further
Intruder alarms.
3 - Anti-code Resets
Limits how many times a user can perform an Anti-code reset. Once
this limit is been reached, the system can only be reset using an
Engineer code. This counter is reset every month or whenever an
Engineers code is entered.
4 - Multiple Knocks
Controls how many times, a zone with the ‘Double Knock’ attribute,
must be activated, before an alarm occurs. The multiple knock count
can be applied to zones on an area basis, see page 66 for details.
5 - Clock Adjustment
Adjusts the accuracy of the clock by subtracting or adding time in
seconds at midnight every night. 0 = -50, 50 = 0 (no correction), 100
= +50.
6 - Quick Count
Set the number of 10milli Second pulses that are required within 30
Seconds in order for a zone with the ‘Quick Response’ attribute to
activate.
7 - Modem Level
When using a Com2400 this option allows adjustment to the
attenuation of the modem.
8 - Language Selection
Various languages are available for the control panels. Listed below are
the language sets, and the languages available. The Language set
number is defined on the product label where applicable by LS1, LS2
or LS3. The 640 has all languages listed available in the control panel.
9 - Country Codes & Defaults
Country codes are used to define Telecoms requirements, and defaults
are loaded if available when the country code is chosen. The following
country codes are available and show the associated defaults loaded
by the panel.
