Zone and Output Numbering 24/48/64/88/168
Expander Zones Keypad Zones
Address
Zones
(Network 1)
Zones
(Network 2)
Address
Zones
Network 1
Zones
Network 2
1
9 - 16
73 - 80
1
Unmapped
Unmapped
2
17 - 24
81 - 88
2
Unmapped
Unmapped
3
25 - 32
89 - 96
3
Unmapped
Unmapped
4
33 - 40
97 - 104
4
Unmapped
Unmapped
5
41 - 48
105 - 112
5
Unmapped
Unmapped
6
49 - 56
113 - 120
6
Unmapped
Unmapped
7
57 - 64
121 - 128
7
Unmapped
Unmapped
8
65 - 72
129 - 136
8
Unmapped
Unmapped
Keypad Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
2
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
3
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
4
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
5
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
6
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
7
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
8
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Expander/OP16 Outputs
Address
Outputs
Network 1
Outputs
Network 2
Outputs
Network 3
Outputs
Network 4
Outputs
Network 5
Outputs
Network 6
Outputs
Network 7
Outputs
Network 8
1
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
2
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
3
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
4
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
5
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
6
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
7
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
