Texecom Premier Elite Series Installation Manual

Engineer Utilities Premier Elite Series Installation Manual
138 INS176-15
Ricochet Diagnostics (V2 Only)
This menu displays information about the live system, and is split into
Premier Elite SmartKey™ and Ricochet enabled devices via Zones
and Users.
Devices
For Devices the following information can be viewed:-
• Routeing
• RSSI
• Alarms and Status
• Device visibility
• Time since last message
Premier Elite SmartKey™
For Premier Elite SmartKey™ the following information can be
viewed:-
• Routeing
• RSSI
• Premier Elite SmartKey™ Button
• Status
Interpreting Keypad Displays
Routeing
The image below shows that Zone 009 is routeing through 14 and
then 7 to the expander, for Premier Elite SmartKey™ this may vary
depending on where & when the reading is taken. If question marks
appear in the display it means the information is not available.
Zone  I
47
RSSI
Each value in the image below represents the RSSI levels in dBm at
each of the hops. If question marks appear on the display it means
the information is not available. Any device showing a level of <20 in
commission mode should be investigated as the poor signal may
affect system/device performance.
Zone  I
 8 7 
@
 If question marks appear it could be because either the system has just
been powered up and information has not been collected yet, or on
large systems the information is not in memory. To populate the display
activate the device and the information should appear.
Device Messages
Zone 
o icoche
The chosen zone does not have a Ricochet
device learned to it.
Zone  I
sg ??? ins ago
shows the last time the device communicated
this represents the last message and could be a
poll, activation or tamper etc.....
Zone  I
h since sg
This is a warning showing that the last
communication from the device was over an
hour ago.
Zone  I
o sg ecd ye
This display shows that no message has been
received yet, this would normally be seen on a
recently powered up system, wait 15 minutes
from power up before checking the diagnostics
information.
Signal Security™
Zone  hoc
????
This display shows information relating to signal
security on an 8XP-W. 4 windows are available
to show information; each window represents
two devices, (Odd & Even device slots). Each
window could show any of the information
detailed in the table below
?
No information is available
_
The chosen device cannot “see” either of the devices
O
The chosen device can see the ODD device(s)
E
The chosen device can see the EVEN device(s)
B
The chosen device can see BOTH devices
Example
Zone  hoc
_E
In this example Zone 9 can see the
devices as detailed below, use the scroll
key to view information about other
devices:-
Display
_

E

Device
1
2
3
4
5
6
7
8
Can see








 On the 32XP-W there are 16 windows to show information from the 32
devices of the system; the format is the same.
Device Status
Zone  hoc
as: aaapd
Secure/OK
Active/Fault
Type
a
A
Mag1
a
A
Mag2/Sho
a
A
Reed/PIR
s
S
Poll/Supervision
p
P
Power/Battery
d
D
Device
t
T
Rear
t
T
Front
Premier Elite SmartKey™ Messages
Use icoche
o icoche
The chosen user does not have a Premier Elite
SmartKey™ associated with them.
Use icoche
o conneced
The Premier Elite SmartKey™ is not switched
on
Use icoche
ogon a K
Shows the battery is OK and the fob has logged
onto the system.
Use icoche
aa a K
Shows the different messages displayed when
the relevant buttons are pressed.
Use icoche
isa a K
Use icoche
lla a K
Use icoche
? a K
Shows which Aux button has been pressed
when in Function Mode.
Use icoche
anic a K
Shows the Panic function has been activated
E o ease
nnon eyos
Use this option ONLY if the panel has been
replaced and not all Premier Elite SmartKey™
are recognised by the new panel, or if the error
tone is heard when learning new Premier Elite
SmartKey™
 This option DOES NOT remove known Premier Elite SmartKey™, use the
Delete option in Setup Users.
Low signal security
For V3 the keypad can display basic signal security information for each device
on an expander. Each device will show H High, M Medium or L Low signal
security. The system is updated live and therefore it is possible to determine
changes by moving devices, or by adding more to the system. The information
displayed replicates what is seen when using Ricochet Monitor.
Low Signal Security Displays
The network, expander and number of devices learnt
to the expander will be shown.
Use the  key to select the expander you wish to
view.
No devices learnt to the expander. 8 spaces available.
2 devices out of eight learnt showing Low signal
security. Adding more devices will improve the
reading, moving them will not.
8 devices on the system, 2 show Medium signal
security. 6 showing Low signal security. Moving the
devices may improve the system.
8 Devices learnt to the system, all devices showing
High signal security, the system is operating perfectly.
