Premier Elite Series Installation Manual Installation
INS176-15 31
Zone and Output Numbering 640
Expander Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1
1 - 8
65 - 72
129 - 136
193 - 200
257 - 264
321 - 328
385 - 392
449 - 456
2
9 - 16
73 - 80
137 - 144
201 - 208
265 - 272
329 - 336
393 - 400
457 - 464
3
17 - 24
81 - 88
145 - 152
209 - 216
273 - 280
337 - 344
401 - 408
465 - 472
4
25 - 32
89 - 96
153 - 160
217 - 224
281 - 288
345 - 352
409 - 416
473 - 480
5
33 - 40
97 - 104
161 - 168
225 - 232
289 - 296
353 - 360
417 - 424
481 - 488
6
41 - 48
105 - 112
169 - 176
233 - 240
297 - 304
361 - 368
425 - 432
489 - 496
7
49 - 56
113 - 120
177 - 184
241 - 248
305 - 312
369 - 376
433 - 440
497 - 504
8
57 - 64
121 - 128
185 - 192
249 - 256
313 - 320
377 - 384
441 - 448
505 - 512
Keypad Zones
Address
Zones
Network 1
Zones
Network 2
Zones
Network 3
Zones
Network 4
Zones
Network 5
Zones
Network 6
Zones
Network 7
Zones
Network 8
1
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
2
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
3
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
4
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
5
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
6
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
7
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
8
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Unmapped
Expander/OP16 Outputs
Address
Outputs
Network 1
Outputs
Network 2
Outputs
Network 3
Outputs
Network 4
Outputs
Network 5
Outputs
Network 6
Outputs
Network 7
Outputs
Network 8
1
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
Exp. 1, 1-8
2
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
Exp. 2, 1-8
3
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
Exp. 3, 1-8
4
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
Exp. 4, 1-8
5
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
Exp. 5, 1-8
6
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
Exp. 6, 1-8
7
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
Exp. 7, 1-8
8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
Exp. 8, 1-8
