Texecom Premier Elite Series Installation Manual

Premier Elite Series Installation Manual Specifications
INS176-15 145
6. Specifications Control Panels
Identifying the Control Panel
Type Code
Description
ASB
Premier Elite 12-W
AEO
Premier Elite 24
AEJ
Premier Elite48
AFG
Premier Elite 48-W 868MHz
AFN
Premier Elite 48-W 433MHz
AEK
Premier Elite 88
ATH
Premier Elite 64-W 868MHz
ATJ
Premier Elite 64-W 433MHz
ATI
Premier Elite 64-W 866MHz
ATH
Premier Elite 64-W Live 868MHz
ATI
Premier Elite 64-W Live 866MHz
AEL
Premier Elite 168
AEZ
Premier Elite 640
Premier Elite 24 (Polymer)
Current
Current Consumption
95mA
Maximum Current Available
0.3A charge
1.1A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah
0.3A
0.48A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Minimum Standby Period
12h
12h
Maximum Recharge Time
72 Hrs
72 Hrs
PD6662
Grade 1
Grade 2
Standby Period
12 Hrs
12 Hrs
Maximum Recharge Time
72 Hrs
72 Hrs
Power Supply
Type A
Rated Input:
100V - 240V @ 50/60Hz; 1A
Rated Output Current @ 55°C::
1.5A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse:
250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current
95mA
Output Voltage Range:
13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type:
sealed lead acid, up to 7Ah, Maximum
recharge time 72h
Battery Low Voltage Signal:
9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection:
8.6V
Over voltage protection trigger:
16V
Fuses
F1 (900mA) Auxiliary 12V Power fuse
(electronic PTC)
F2 (900mA) Digicom Power (electronic
PTC)
F3 (900mA) Network 1 fuse (electronic
PTC)
F4 (900mA) Bell/Strobe fuse
(electronic PTC)
F6 (1.6 Amp) Battery fuse (electronic
PTC)
Housing
3mm Polycarbonate
Dimensions (W x H x D)
305mm x 263mm x 98mm
Battery Compartment
One 12V 7.0Ah battery
Packed Weight
1.5 Kg (Approx)
Premier Elite 24 (Metal)
Current
Current Consumption
95mA
Maximum Current Available
0.75A charge
1.0A
0.3A charge
1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 7Ah
0.3A
0.48A
0.19A
0.13A
0.021A
1 x 17Ah
0.3A
1.32A
0.61A
0.47A
0.18A
0.75A
1.0A
0.61A
0.47A
0.18A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby Period
12h
12h
30h *
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah
< 24Hrs
0.3 A
1 x 17Ah
< 24Hrs
0.75 A
< 72Hrs
0.3 A
Power Supply
Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse:
250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current
95mA
Output Voltage Range:
13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type:
sealed lead acid, up to 18Ah,
Maximum recharge time 24h (0.75A
charge rate) 72h (0.3A charge rate)
Battery Low Voltage Signal:
9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection:
8.6V
Over voltage protection trigger:
16V
Fuses
F1 (900mA) Auxiliary 12V Power fuse
(electronic PTC)
F2 (900mA) Digicom Power (electronic
PTC)
F3 (900mA) Network 1 fuse (electronic
PTC)
F4 (900mA) Bell/Strobe fuse
(electronic PTC)
F6 (1.6 Amp) Battery fuse (electronic
PTC)
Housing
1mm Mild Steel
Dimensions (W x H x D)
315mm x 415mm x 100mm
Battery Compartment
Up tp one 18Ah battery
Packed Weight
4.5 Kg (Approx)
Premier Elite 12/24/48/64-W
Current
Current Consumption
150mA
Maximum Current Available
0.3A charge
1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
1 x 7Ah
0.3A
0.433A

Texecom Premier Elite Series Specifications

General

Event Log	1000 events
Expanders	Supports up to 8 expanders
Wired Zones	Up to 48 wired zones
Wireless Zones	Up to 64 wireless zones
Batteries	12V 7Ah
Tamper Protection	Yes
Outputs	Up to 8 outputs
Battery Backup	Yes
Compatibility	Compatible with Texecom accessories
Dimensions	Varies depending on model
Weight	Varies depending on model
