Texecom Premier Elite Series Installation Manual

Specifications Premier Elite Series Installation Manual
146 INS176-15
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Minimum Standby Period
12h
12h
Maximum Recharge Time
72 Hrs
72 Hrs
PD6662
Grade 1
Grade 2
Standby Period
12 Hrs
12 Hrs
Maximum Recharge Time
72 Hrs
72 Hrs
Power Supply
Type A
Rated Input:
100V - 240V @ 50/60Hz; 1A
Rated Output Current @ 55°C::
1.5A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse:
250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current
150mA
Output Voltage Range:
13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type:
sealed lead acid, up to 7Ah, Maximum
recharge time 72h
Battery Low Voltage Signal:
9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection:
8.1V
Over voltage protection trigger:
16V
Fuses
F6 PTC (0.9A) Auxiliary 12V Power
fuse
F4 PTC (0.9 A) Network 1 fuse
F5 PTC (0.9 A) Bell/Strobe fuse
Panel
24/48 & 64-W
12-W
Housing
3mm Polycarbonate
3mm Polycarbonate
Dimensions (W x H x D)
305mm x 263mm x
98mm
283mm x 229mm x
85mm
Battery Compartment
One 12V 7.0Ah battery
One 12V 7.0Ah battery
Packed Weight
1.7 Kg (Approx)
1.7 Kg (Approx)
Premier Elite 48/88/168
Current
Current Consumption
125mA
Maximum Current Available
0.75A charge
1.0A
0.3A charge
1.9A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 7Ah
0.3A
0.458A
0.166A
0.108A
1 x 17Ah
0.3A
1.29A
0.583A
0.441A
0.158A
0.75A
1.0A
0.583A
0.441A
0.1588A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby Period
12h
12h
30h *
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Jumper Settings
Battery Arrangement
Recharge
Time
Battery Charge Selector
1 x 7Ah
< 24Hrs
0.3 A
1 x 17Ah
< 24Hrs
0.75 A
< 72Hrs
0.3 A
Power Supply
Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse:
250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1 & 2
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current
125mA
Output Voltage Range:
13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type:
sealed lead acid, up to 18Ah,
Maximum recharge time 72h
Battery Low Voltage Signal:
9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection:
8.6V
Over voltage protection trigger:
16V
Fuses
F1 (1Amp) Auxiliary 12V Power fuse
F2 (1.6 Amp) Battery fuse (electronic
PTC)
F3 (1 Amp) Network 1 fuse
F4 (1 Amp) Bell/Strobe fuse
F5 (1 Amp) Network 2 fuse (168 only)
Housing
1mm Mild Steel
Dimensions (W x H x D)
315mm x 415mm x 100mm
Battery Compartment
Up tp one 18Ah battery
Packed Weight
4.5 Kg (Approx)
Premier Elite 640
Current
Current Consumption
125mA
Maximum Current Available
0.75A charge
1.0A
Rated Output
Battery
Arrangement
Battery
Charge
Rated Output (Amps)
12h
24h
30h
60h
1 x 17Ah
0.75A
1.0A
0.558A
0.416A
0.133A
Standby and Recharge Times
EN50131-1
Grade 1
Grade 2
Grade 3
Minimum Standby Period
12h
12h
30h *
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
PD6662
Grade 1
Grade 2
Grade 3
Standby Period
12 Hrs
12 Hrs
24 Hrs **
Maximum Recharge Time
72 Hrs
72 Hrs
24 Hrs
*30h if MAINS FAIL is reported to ARC, otherwise 60h
**This time may be halved if mains failure is signalled to an ARC
Power Supply
Type A
Rated Input:
Rated Output Current@40°C:
220V - 240V @50/60Hz; 1A
2.5A MAX
Rated Input:
Rated Output Current@40°C:
100VV - 120V @50/60Hz; 1A
2.3A MAX
Rated Output Voltage:
13.&Vdc +/- 2%
Mains Terminal Block Fuse:
250Vac; 3-3.15A Slow/Medium Blow
Maximum rating of each power output (note that these are not considered to be
"independent power outputs" according to EN50131-6
Aux 12V
Bell/Strobe
Network 1 & 2
Battery
DC+/DC-
1.0A
1.0A
1.0A
1.6A
1.0A
Standby Current
150mA
Output Voltage Range:
13.0V to 13.9V
Maximum Ripple Voltage:
0.5V pk-pk
Battery type:
sealed lead acid, up to 18Ah,
Maximum recharge time 72h
Battery Low Voltage Signal:
9.5V
Power Output Fault signal:
10.5V (with mains present)
Deep Discharge protection:
8.6V
Over voltage protection trigger:
16V
Fuses (Electronic PTC)
F3 (1600 mA) Battery
F4 (250mA) Speaker
F5 (900mA) Network 1
F6 (900mA) Bell/Strobe
F7 (900mA) Network 2
F8 (900mA) Network 3
F9 (900mA) Network 4
F10 (900mA) Network 5
F11 (900mA) Network 6
F12 (900mA) Network 7
F13 (900mA) Network 8
F14 (900mA) Auxiliary 12V
Housing
1mm Mild Steel
Dimensions (W x H x D)
315mm x 415mm x 100mm
Battery Compartment
Up tp one 18Ah battery
Packed Weight
4.5 Kg (Approx)
General (All Models)
Data Network
4-wire standard 7/0.2 alarm
cable up to 500m Star, Daisy
Chain or any combination of the
two
Remote Keypads
12-W
24 &48 & 48/64-W
Up to 2
Up to 4

Texecom Premier Elite Series Specifications

General

Event Log	1000 events
Expanders	Supports up to 8 expanders
Wired Zones	Up to 48 wired zones
Wireless Zones	Up to 64 wireless zones
Batteries	12V 7Ah
Tamper Protection	Yes
Outputs	Up to 8 outputs
Battery Backup	Yes
Compatibility	Compatible with Texecom accessories
Dimensions	Varies depending on model
Weight	Varies depending on model
