UDL & Digi Options Premier Elite Series Installation Manual
98 INS176-15
The system has the following UDL download
options:
Download Call Back Number 1
This is the telephone number that is dialled by the modem when ‘Call-
back Number 1’ is requested by the remote UDL computer. This
telephone number can be up to 24 digits.
Download Call Back Number 2
This is the telephone number that is dialled by the modem when ‘Call-
back Number 2’ is requested by the remote UDL computer. This
telephone number can be up to 24 digits.
Download Call Back Number 3
This is the telephone number that is dialled by the modem when ‘Call-
back Number 3’ is requested by the remote UDL computer. This
telephone number can be up to 24 digits.
UDL Password is:
When the remote downloading computer dials into the system, the
control panel compares the UDL password sent by the computer with
UDL password stored in the control panel. If the passwords match,
access to the control panel is granted, if they don’t match, access is
denied.
If more than three attempts at reporting are made with a wrong
password, the modem will lock out for 4 hours or until a Master
User code is entered.
The UDL password programmed in this option must also be
programmed in the customer account on the remote
downloading computer. This password can be up to 16
characters (numbers and letters).
If no UDL Password has been programmed, access to the
control panel can be gained by using the engineers code as
the UDL Password.
A UDL password MUST be programmed when using Texecom
Connect.
UDL Options
There are 6 UDL options that affect how and when access to the
control panel via the Wintex UDL software is allowed.
Select options by pressing keys 1 to 6 (a letter on the display means
the option is selected, a Dot on the display means the option is not
selected).
The following UDL options are available:
A - DL Attended
The system will not allow the remote downloading computer access
without user authorisation first.
M - Man Call-Back
The system will not use the automatic call back feature. The user
must instruct the panel to call back the remote downloading
computer.
The Auto Call-Back feature operates as follows:
• The remote downloading computer calls the control panel
and establishes a connection
• The UDL password is verified and the remote downloading
computer instructs the panel to call it back using one of the
3 call back numbers
• The panel hangs up and dials the requested number and re-
establishes the connection with the remote downloading
computer
D - Call Defeat
The modem will answer incoming calls as follows:
• The modem must detect one or more rings and the number
of rings must NOT exceed the value set up in ‘Rings
Required’
• When the ringing stops, the panel will start a 30 second
delay timer
• If the modem detects ringing before the timer expires it will
answer the call immediately
L - Armed DL Limited
The panel will not allow download access when the system is armed
(also see below).
A - Any Area Armed
The panel will not allow download access when any areas are armed.
K - Online RKP = Off
The control panel cannot be accessed using the ‘On-line’ keypad
feature of the Wintex UDL software.
Rings Required
This counter controls the number of rings the modem needs to see
before it will answer the call (Default = 003).
UDL Dial Attempt
If a ‘Call-Back’ is started, this option controls how many times the
modem will try to call the remote downloading computer before
giving up (Default = 003).
Enter the number of dialling attempts. This number is limited to
9. If this value is set to 0, the communicator will never dial out.
This only affects the modem for download access and does
not affect the operation of the communicator in any way.
