TOHATSU BFT75A - Page 100

3-23
dummyheaddummyhead
MAINTENANCE
[1] Throttle rod hole in the throttle body
[1] Detent spring roller
[2] Tilting shaft cam
[1] Gear case
[1] Grease fitting
(Tilting shaft outer surface)
Engine oil
[1]
[1]
[2]
[1]
Gear oil
[1]
[1]
[1] Grease fitting
(Tilting shaft outer surface)
[1] Tilting shaft threads
[1]
[1] Mount frame
[1]
