12-3
dummyheaddummyhead
LUBRICATION SYSTEM
LUBRICATION SYSTEM DIAGRAM
EOP SENSOR
CRANKSHAFT
CAMSHAFT
VTEC SOLENOID VALVE
ROCKER SHAFT
INTAKE
ROCKER ARM
EXHAUST
ROCKER ARM
OIL PUMP
RELIEF VALVE
OIL STRAINER
OIL CASE
CAM CHAIN JET 2
PISTON
CAM CHAIN JET 1
OIL FILTER
