MAINTENANCE
SPARK PLUG CHECK/REPLACEMENT
REMOVAL
Remove the engine cover.
Remove the bolt [1] and plug maintenance cover [2].
Disconnect the ignition coil 3P connector [1].
Remove the bolts [2] and ignition coils [3]. Take care
not to an impact or drop the ignition coils. Replace the
ignition coil if dropped.
Clean any dirt from around the spark plug bases.
Use a spark plug wrench [1] and remove the spark
plugs.
