TOHATSU BFT75A - Installation

6-7
dummyheaddummyhead
ENGINE COVER
Remove the L. engine under cover [1] and R. engine under cover [2] from the outboard motor.
INSTALLATION
Align the L. engine under cover installation groove [1]
with the under cover seal A [2] of the mount case as
shown, and install the L. engine under cover [3] on the
outboard motor from the top of the outboard motor.
[1]
[2]
[1]
[3]
[2]
