TOHATSU BFT75A - Shift Slider;Propeller Shaft Removal;Installation

16-19
dummyheaddummyhead
GEAR CASE
SHIFT SLIDER/PROPELLER SHAFT
REMOVAL/INSTALLATION
REMOVAL
Remove the shift shaft holder (page 16-18).
Remove the propeller shaft [1], two ball bearings [2],
and O-ring [3] from the propeller shaft holder [4].
Remove the two water seals [5] from the propeller shaft
holder.
Remove the cross pin ring [1] and shifter pin [2], and
then remove the clutch shifter [3].
Remove the shift slider [1] and the two steel balls (#7)
[2] from the propeller shaft [3]. Take care not to let the
steel balls pop out of the shift slider.
[4]
[3]
[2]
[1]
[5]
[3]
[1]
[2]
[2]
[3]
[1]
