ENGINE COVER
FRONT SEPARATE COVER REMOVAL/INSTALLATION
REMOVAL
Remove the engine cover.
Remove the bolt [1], special bolt (6 x 17 mm) [2], special bolt (6 x 37 mm) [3] and, front separate cover [4].
INSTALLATION
Install the front separate cover [1] on the outboard
motor and loosely tighten the bolt [2], special bolt (6 x
17 mm) [3], and special bolt (6 x 37 mm) [4].
• Make sure that the shoulder on each special bolt
goes into hole on the front separate cover.
Tighten each bolt to the specified torque in the
numbered order shown.
Install the engine cover.
[2]
[1]
[3]
[4]
TORQUE:
Special bolt: 10 N·m (1.0 kgf·m, 7 lbf·ft)
bolt: 5 N·m (0.51 kgf·m, 3.7 lbf·ft)
[1]
[3]
[2]
[4]
1.
2.
3.
