TOHATSU BFT75A - Fuel Pump (High Pressure Side);Vapor Separator Removal;Installation

5-76
dummyheaddummyhead
FUEL SYSTEM
Connect the 2P connectors [1] to the corresponding
injectors.
Install the three harness band clips [2].
Install the following:
– L. engine under cover (page 6-7)
– Engine cover
FUEL PUMP (HIGH PRESSURE SIDE)/
VAPOR SEPARATOR REMOVAL/
INSTALLATION
REMOVAL
Disconnect the battery cable from the battery negative
(–) terminal.
Relieve the fuel pressure (page 5-66).
Remove the following:
– Engine cover
– L. engine under cover (page 6-5)
Disconnect the pressure regulator control tube [1] and
the vinyl tube [2] from the intake manifold.
Remove fuel tube clamp D [3] from the pressure
regulator control tube.
[2]
[1]
Gasoline is highly flammable and explosive.
You can be burned or seriously injured when
handling fuel.
• Keep heat, sparks, and flame away.
• Wipe up spills immediately.
• Handle fuel only outdoors.
[1]
[3]
[2]
