SPECIFICATIONS
SPECIFICATIONS
SERIAL NUMBER LOCATION
The engine serial number is stamped on the right side of cylinder block and the product identification number is located on the right
stern bracket. Always specify these numbers when inquiring about the engine or when ordering parts in order to obtain the correct
parts for the outboard motor being serviced.
SPECIFICATIONS
DIMENSIONS AND WEIGHTS
ENGINE SERIAL NUMBER
PRODUCT IDENTIFICATION NUMBER
Model BF75DK3
Description code BBAJ
Type LHGX LRTA LRTC LRTX
Overall length 904 mm (35.6 in) 746 mm (29.4 in)
Overall width 646 mm (25.4 in) 449 mm (17.7 in)
Overall height 1,566 mm (61.7 in)
Dry weight (*1) 167 kg (368 lbs) 165 kg (364 lbs)
Operating weight
(including oil)
172 kg (379 lbs) 170 kg (375 lbs)
*1: Including the propeller weight: 3.0 kg (6.6 lbs)
Model BF80A
Description code BBLJ
Type LHTD LRTL LRTD XRTL
Overall length 904 mm (35.6 in) 746 mm (29.4 in)
Overall width 646 mm (25.4 in) 449 mm (17.7 in)
Overall height 1,566 mm (61.7 in) 1,693 mm (66.7 in)
Dry weight (*1) 171 kg (377 lbs) 165 kg (364 lbs) 171 kg (377 lbs)
Operating weight
(including oil)
176 kg (388 lbs) 170 kg (375 lbs) 176 kg (388 lbs)
*1: Including the propeller weight: 3.0 kg (6.6 lbs)
Model BF90DK4
Description code BBCJ
Type LHGX LRTA LRTC XRTA XRTC
Overall length 904 mm
(35.6 in)
746 mm
(29.4 in)
Overall width 646 mm
(25.4 in)
449 mm
(17.7 in)
Overall height 1,566 mm
(61.7 in)
1,693 mm
(66.7 in)
Dry weight (*1) 168 kg
(370 lbs)
166 kg
(366 lbs)
172 kg
(379 lbs)
Operating weight
(including oil)
173 kg
(381 lbs)
171 kg
(377 lbs)
177 kg
(390 lbs)
*1: Including the propeller weight: 3.0 kg (6.6 lbs)
