SPECIFICATIONS
DIMENSIONAL DRAWING
REMOTE CONTROL TYPE
Unit: mm (in)
L type: 1,566 (61.7) X type: 1,693 (66.7)
30°
365 (14.4)
L
t
y
p
e
:
R1
,
0
5
6
(
4
1
.
6
)
X
t
y
p
e
:
R1
,
1
7
4
(
4
6
.
2
)
L type: 537 (21.1) X type: 664 (26.1)
12°
44 (1.7)
746 (29.4)
76.2 (3.0)
596 (23.5)
48.4 (1.91)
449 (17.7)
R
8
0
7
(
3
1
.
8
)
