SPECIFICATIONS
Propeller shaft
+0.03 -0.04
Ø16.9 (Ø0.67 )
+0.001 -0.002
0 -0.1
Ø24.9
(Ø0.98 )
0 -0.004
-0.020 -0.041
Ø30
(Ø1.2 )
-0.0008 -0.0016
+1° 0°
30
°
M18 x 1.5
ANSI INV.S.16/32 x 15T x 30°
28.5 mm
(1.12 in)
57.5 ± 0.5 mm
(2.26 ± 0.02 in)
60 mm
(2.36 in)
154.5 mm (6.1 in)
Ø4
(Ø0.2)
7 mm
(0.3 in)
