FUEL SYSTEM
Disconnect the IAC valve 2P connector [1], and EOP
sensor 3P connector [2].
Remove the two harness band clips [3].
Remove the three harness band clips [1] from the
intake manifold.
Release tube D [1] from the clamp of the intake
manifold. Remove the three bolts [2], two bolt/washers
[3], and the two nuts [4], and remove the intake
manifold [5].
[3]
[1]
[2]
[1]
[1]
[3]
[4]
[2]
[5]
