7-7
dummyheaddummyhead
CHARGING SYSTEM
Remove the two bolts [1] and ECM.
Remove the harness band clip [1] from the electronic
parts case.
Remove the harness band clip [1] from the electronic
parts case.
Release the stator harness [2] from the electronic parts
case clamp and disconnect the stator 3P connector [3].
Release the stator harness [1] from the projection [2] of
the electronic parts case.
[1]
[1]
[1]
[2]
[3]
[1]
[2]
