TOHATSU BFT75A - Page 296

9-11
dummyheaddummyhead
STARTING SYSTEM
Remove the yoke [1] from the armature/rear bracket
assembly [2].
Remove the two screws [1] and rear bracket [2] from
the armature [3].
Remove the brush holder [1] from the armature [2].
Remove the steel ball [1] and three planetary gears [2]
from the front bracket [3].
[2]
[1]
[1]
[2]
[3]
[2]
[1]
[1]
[3]
[2]
